Some Words about Logstash Filters and Dates

date

Some time ago I published an article about how to store the NetEye SMS Protocol log into an ELK environment. Now, after using it some times, I discovered that it was not completely correct as the time/date functions for the Logstash filters are a bit more complicated. In particular, it was that the date was written in the SMS protocol file in this way:

June 29th 2016, 10:30:22 CEST 2016

And we used this Logstash date filter to convert it:

date {
          locale = "en"
          match  = [ "sms_timestamp_text", "EEE MMM dd HH:mm:ss" ]
      }

Now it seemed that it would work, but after some time (some days until the start of the next month) we discovered that the date in the first days of the month would look like:

July  1th 2016, 10:30:22 CEST 2016

As we had a textual timezone and date filters do not support this, in the first draft we had this rule to be able to parse the sms_timestamp_text:

match =>[ "message", "%{SMS_TIMESTAMP_SHORT:sms_timestamp_text}
%{WORD:timezone} %{YEAR}:%{INT:sms_phonenumber}:%{GREEDYDATA:sms_text}"

This are the pattern we would use for this:

SMS_TIMESTAMP_SHORT %{DAY} %{MONTH} +%{MONTHDAY} %{TIME}
SMS_TIMESTAMP %{SMS_TIMESTAMP_SHORT} %{WORD:tz} %{YEAR}

This would all work correctly, but …

We discovered that our filter would not work with that as we had “dd” for 2 digit day. Now, how would we do this as the date cannot be matched by “d”, neither by “dd”? After studying the filter rules I discovered the solution. It is possible to have “or” rules inside the date and so being able to match more than one date format. So we changed the filter in this way:

date {
          locale = "en"
          match   => [ "sms_timestamp_text", "EEE MMM dd HH:mm:ss Z yyyy", "EEE MMM  d HH:mm:ss Z yyyy" ]
      }

You see the new Z and yyyy parameters because if we do not match a complete date it will not work correctly. To be able to parse this correctly now I discovered that the pattern match had to change in this way:

match => [ "message", "%{SMS_TIMESTAMP:sms_timestamp_text}:%{INT:sms_phonenumber}:%{GREEDYDATA:sms_text}" ]

As I told earlier, Logstash cannot parse textual time zones, but this is what we have here. What should we do? We know that our date is in Western Europe so we have a solution for this mutate tag in this way:

mutate  {
      gsub => ["sms_timestamp_text", "CEST", "+0200"]
      }
mutate  {
      gsub => ["sms_timestamp_text", "CET", "+0100"]
      }

In this way the Z tag can work and we parse the date in the right format.

Problem solved, logs can be parsed correctly.
